- The Router with the highest OSPF interface priority on a segment becomes the DR.
This is provided using the interface command: ip ospf priority <0 - 255>
The default OSPF priority is 1.
- Router with the next highest OSPF interface priority becomes the BDR.
- If router priorities are equal, the highest Router ID (RID) breaks the tie.
- The OSPF Router ID for a router is found by:
1. The router-id <ip-address> config-router command.
2. If that doesn’t exist, then the highest IP address on a loopback is used.
3. If that doesn’t exist, then the highest IP address on an up physical is used.
Are you serious?? The router with the highest priority becomes the DR. if the priority is equal, the router with the highest ip configured on an interface , make this router become the DR! keep study dude!
